IS25LE512M
IS25WE512M
Integrated Silicon Solution, Inc.- www.issi.com
149
Rev. A6
06/16/2025
Figure 8.111 Read DYB Sequence In SPI Mode(FAh [EXTADD=1] or E0h, 4-byte address)
Instruction = FAh/E0h
CE #
SCK
SI
SO
0
1
...
7
8
9
...
39
40
41
42
43
44
45
46
47
Mode 3
Mode 0
4-byte Address
tV
7
3
2
1
0
6
5
4
