DSPIC33FJMC202ESS Datasheet(PDF) 158 Page - Microchip Technology |
|
|
|||||||||||||||||||||||||||||
DSPIC33FJMC202ESS Datasheet(HTML) 158 Page - Microchip Technology |
|
|
158 / 330 page  dsPIC33FJ32MC202/204 and dsPIC33FJ16MC304 DS70283K-page 158 © 2007-2012 Microchip Technology Inc. 14.3 Output Compare Control Register REGISTER 14-1: OCxCON: OUTPUT COMPARE x CONTROL REGISTER U-0 U-0 R/W-0 U-0 U-0 U-0 U-0 U-0 — —OCSIDL — — — — — bit 15 bit 8 U-0 U-0 U-0 R-0 HC R/W-0 R/W-0 R/W-0 R/W-0 — — — OCFLT OCTSEL OCM<2:0> bit 7 bit 0 Legend: HC = Cleared in Hardware HS = Set in Hardware R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’ -n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown bit 15-14 Unimplemented: Read as ‘0’ bit 13 OCSIDL: Stop Output Compare in Idle Mode Control bit 1 = Output Compare x will halt in CPU Idle mode 0 = Output Compare x will continue to operate in CPU Idle mode bit 12-5 Unimplemented: Read as ‘0’ bit 4 OCFLT: PWM Fault Condition Status bit 1 = PWM Fault condition has occurred (cleared in hardware only) 0 = No PWM Fault condition has occurred (This bit is only used when OCM<2:0> = 111.) bit 3 OCTSEL: Output Compare Timer Select bit 1 = Timer3 is the clock source for Compare x 0 = Timer2 is the clock source for Compare x bit 2-0 OCM<2:0>: Output Compare Mode Select bits 111 = PWM mode on OCx, Fault pin enabled 110 = PWM mode on OCx, Fault pin disabled 101 = Initialize OCx pin low, generate continuous output pulses on OCx pin 100 = Initialize OCx pin low, generate single output pulse on OCx pin 011 = Compare event toggles OCx pin 010 = Initialize OCx pin high, compare event forces OCx pin low 001 = Initialize OCx pin low, compare event forces OCx pin high 000 = Output compare channel is disabled |
|
