Table 10.9 lists other specifications for the ADC not covered in Tables 10.6, 10.7, and 10.8.
Table 10.9. ADC Specifications*
Parameter
Min
Typ
Max
Units
VREF
1.17
1.2
1.23
V
VREF output current
1
mA
VREF load capacitance
10
nF
Minimum input voltage
0
V
Maximum input voltage
VREF
V
Single-ended signal range
0
VREF
V
Differential signal range
–VREF
+VREF
V
Common mode range
0
VREF
V
Input referred ADC offset
–10
10
mV
Input Impedance
1 MHz sample clock
6 MHz sample clock
Not sampling
1
0.5
10
M
*Note: The signal-ended ADC measurements are limited in their range and only guaranteed for accuracy within the limits
shown in this table. The ADC's internal design allows for measurements outside of this range (±200 mV), but the
accuracy of such measurements is not guaranteed. The maximum input voltage is of more interest to the differential
sampling where a differential measurement might be small, but a common mode can push the actual input voltage on
one of the signals towards the upper voltage limit.
