5 / 6 page

www.roithner-laser.com

Operating Regime

We recommend to use Quasi Continuous Wave (QCW) mode with duty cycle 50% or 25% to obtain maximum

average optical power and Pulse mode to obtain maximum peak power. Hard CW (continuous wave) mode is

NOT recommended.

LED Basic Circuit Connection

LED With Thermoelectric Module

Quasi Continuous Wave (QCW) mode

Pulse Mode
