KEMET Part Number: SSHB21H-R06825

KEMET, SSHB21H, Commercial Grade, 0.0825 H

Dimensions

L

26mm MAX

T

23mm MAX

H

15.5mm MAX

S

15mm +/-0.5mm

S1

21mm NOM

LL

3.5mm +/-0.5mm

F

0.8mm NOM

Packaging Specifications

Weight: 14 g

Packaging: Bulk

General Information

Series: SSHB21H

Style: Through-Hole Choke

Description:

Common Mode Filter, SS Coils,

SSHB21H, High Impedance

Type

RoHS: Yes

Miscellaneous: Temperature Rise Maximum: 60

K

Notes: Marking: R06 Lot No.

Specifications

Inductance: 82.5 mH (10 kHz)

Temperature Range: -25/+120C

Rated Temperature: 120C

Current: 0.6 Amps

Voltage AC: 250 VAC

Withstanding Voltage: 2400 VDC

Insulation Resistance: 100 MOhms
