CRE1 Series

Isolated 1W Single Output Isolated DC-DC Converters

KDC_CRE1.D02 Page 13 of 14

www.murata-ps.com/support

PACKAGE SPECIFICATIONS (continued)

RECOMMENDED FOOTPRINT DETAILS

TUBE OUTLINE DIMENSIONS

Tube Quantity (MC): 35

(MEC): 30

Unless otherwise specified all dimensions in mm [inches] ±0.55mm [0.022].

Tube Length (MC&MEC) : 475±2.0 (18.70±0.07).

CRE1S0505MC

CRE1S0505MEC

9.40 (0.370)

2.10 (0.083)

6.70 (0.264)

14.35 (0.565)

0.60±0.15 (0.024±0.006)

9.70

(0.382)

2.00 (0.079)

7.62

(0.3)

1.00 (0.040) MIN

2.54 (0.1)

9.05 (0.36)
