Page 1 of 2

Notes

A. Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.

B. Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.

C. The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled

to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp

Level 17 (LO Power +17 dBm) 20 to 750 MHz

Frequency Mixer

High IP3

Demo Board MCL P/N: TB-02+

Suggested PCB Layout (PL-051)

Maximum Ratings

Pin Connections

REV. A

M151107

ADE-751H+

ED-14942/1

DJ/CP/AM

150518

ADE-751H+

CASE STYLE: CD541

Outline Dimensions (

)

inch

mm

Outline Drawing

Electrical Schematic

Permanent damage may occur if any of these limits are exceeded.

Electrical Specifications at 25°C

Parameter

Min.

Typ.

Max.

Unit

Frequency Range, RF

20

—

750

MHz

Frequency Range, LO

50

—

780

MHz

Frequency Range, IF

DC

—

250

MHz

Conversion Loss

—

6.5

8.0

dB

LO to RF Isolation

28

42

—

dB

LO to IF Isolation

27

40

—

dB

IP3

—

27

—

dBm

RF Input Power at 1 dB Compression

—

+9

—

dBm

Features

• high IP3, 27 dBm typ.

• low conversion loss, 6.5 dB typ.

• good L-R isolation, 42 dB typ.

• low profile package

• aqueous washable

• protected by U.S. Patent 6,133,525

Applications

• cellular

LO

6

RF

4

IF

3

GROUND

1,2,5

A

B

C

D

E

F

G

.272

.310

.220

.100

.082

.055

.100

6.91

7.87

5.59

2.54

2.08

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.15

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

200mW

IF Current

40mA

PCB Land Pattern

Suggested Layout,

Tolerance to be within ±

� .002

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

IP3

(dBm)

RF

LO

LO

+17dBm

LO

+17dBm

LO

+17dBm

LO

+17dBm

LO

+17dBm

LO

+17dBm

Typical Performance Data

20.10

50.10

6.55

62.00

64.65

1.24

2.86

28.64

50.10

80.10

6.51

57.54

61.04

1.22

2.96

40.05

100.10

130.10

6.51

53.50

58.09

1.21

2.77

38.21

150.10

180.10

6.50

50.42

54.59

1.21

2.83

32.38

200.10

230.10

6.45

48.87

52.36

1.21

2.67

30.83

250.10

280.10

6.37

47.00

49.43

1.20

2.81

30.69

300.10

330.10

6.30

46.10

48.17

1.20

2.69

29.85

350.10

380.10

6.31

44.73

45.32

1.19

2.81

28.17

400.10

430.10

6.21

44.09

45.53

1.19

2.68

27.83

450.10

480.10

6.14

43.50

42.41

1.18

2.83

28.33

500.10

530.10

6.20

42.96

42.40

1.21

2.70

34.04

550.10

580.10

6.05

42.26

41.46

1.16

2.78

27.56

600.10

630.10

6.06

42.54

39.50

1.14

2.76

24.27

650.10

680.10

6.11

42.37

37.81

1.14

2.98

27.81

700.10

730.10

6.18

42.01

37.68

1.14

2.93

29.20

710.10

740.10

6.14

41.83

37.47

1.12

2.96

28.44

720.10

750.10

6.12

41.70

37.39

1.11

2.97

27.37

730.10

760.10

6.14

41.50

37.25

1.11

2.97

26.07

740.10

770.10

6.13

41.19

37.16

1.11

2.99

25.24

750.10

780.10

6.10

40.97

37.19

1.10

2.97

24.34

+RoHS Compliant

The +Suffix identifies RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualifications

Available Tape and

Reel

at no extra cost

Reel Size

Devices/Reel

7”

20, 50, 100, 200, 500

13”

500,1000
