background image
https://www.phoenixcontact.com/us/products/2900330
12/15/2015   Page 3 / 7
Relay Module - PLC-RPT- 24DC/21-21 - 2900330
Technical data
Connection data input side
Conductor cross section solid
0.14 mm² ... 2.5 mm²
Conductor cross section flexible
0.14 mm² ... 2.5 mm²
Conductor cross section AWG
26 ... 14
Connection data output side
Connection name
Contact side
Connection method
Push-in connection
Stripping length
8 mm
Conductor cross section solid
0.14 mm² ... 2.5 mm²
Conductor cross section flexible
0.14 mm² ... 2.5 mm²
Conductor cross section AWG
26 ... 14
General
Operating mode
100% operating factor
Degree of protection
RT III (Relay)
Mechanical service life
3 x 107 cycles
Flammability rating according to UL 94
V0
Designation
Standards/regulations
Standards/regulations
IEC 60664
EN 50178
IEC 62103
Rated surge voltage/insulation
6 kV (safe isolation: control side / contact side)
Pollution degree
2
Overvoltage category
III
Mounting position
any
Assembly instructions
In rows with zero spacing
Standards and Regulations
Connection in acc. with standard
CUL
Designation
Standards/regulations
Standards/regulations
IEC 60664
EN 50178
IEC 62103
Rated surge voltage/insulation
6 kV (safe isolation: control side / contact side)
Pollution degree
2
Overvoltage category
III
Flammability rating according to UL 94
V0
