background image
https://www.phoenixcontact.com/us/products/2900191
07/15/2016   Page 3 / 9
Relay Module - PLC-RSC- 12DC/21-21/C1D2 - 2900191
Technical data
Connection data output side
Connection method
Screw connection
Stripping length
8 mm
Screw thread
M3
Conductor cross section solid
0.14 mm² ... 2.5 mm²
Conductor cross section flexible
0.14 mm² ... 2.5 mm²
Conductor cross section AWG
26 ... 14
General
Operating mode
100% operating factor
Degree of protection
RT III (Relay)
Mechanical service life
3 x 107 cycles
Flammability rating according to UL 94
V0
Degree of pollution
3
Overvoltage category
III
Designation
Standards/regulations
Standards/regulations
IEC 60664
EN 50178
IEC 62103
Rated surge voltage/insulation
6 kV (safe isolation: control side / contact side)
Degree of pollution
3
Overvoltage category
III
Mounting position
any
Assembly instructions
In rows with zero spacing
Standards and Regulations
Designation
Standards/regulations
Standards/regulations
IEC 60664
EN 50178
IEC 62103
Rated surge voltage/insulation
6 kV (safe isolation: control side / contact side)
Degree of pollution
3
Overvoltage category
III
Flammability rating according to UL 94
V0
Classifications
eCl@ss
eCl@ss 4.0
27371001
