PR2-RSC3-LV-120AC datasheet(2/6 Pages) PHOENIX

2 / 6 page

https://www.phoenixcontact.com/pi/products/2834740

07/23/2018 Page 2 / 6

Relay Module - PR2-RSC3-LV-120AC/4X21AU - 2834740

Technical data

Coil side

Nominal input voltage UN

120 V AC

Typical input current at UN

11 mA (at 50 Hz)

9 mA (At 60 Hz)

Typical response time

4 ms ... 10 ms

Typical release time range

3 ms ... 12 ms

Protective circuit

Varistor

Operating voltage display

LED red

Power dissipation for nominal condition

1.32 W

Contact side

Contact type

4 PDTs

Type of switch contact

Single contact

Contact material

AgNi, hard gold-plated

Maximum switching voltage

250 V AC/DC

Minimum switching voltage

1 V

Min. switching current

1 mA

Maximum inrush current

12 A (15 ms)

Limiting continuous current

5 A

Interrupting rating (ohmic load) max.

120 W (at 24 V DC)

100 W (at 48 V DC)

78 W (at 60 V DC)

55 W (at 110 V DC)

80 W (at 220 V DC)

1250 VA (for 250 V AC)

General

Test voltage relay winding/relay contact

2 kV (50 Hz, 1 min.)

Test voltage relay contact/relay contact

2 kV (50 Hz, 1 min.)

Operating mode

100% operating factor

Degree of protection

RT I (Relay)

Mechanical service life

5x 107 cycles

Mounting position

any

Assembly instructions

In rows with zero spacing

Connection data input side

Connection name

Coil side

Connection method

Screw connection

Stripping length

7 mm

Conductor cross section solid

0.14 mm² ... 2.5 mm²

Conductor cross section flexible

0.14 mm² ... 2.5 mm²

Conductor cross section AWG

26 ... 14

Connection data output side
