10/27/2014 Page 3 / 6

Relay Module - PLC-RSP- 48DC/21-21AU - 2912594

Technical data

Contact side

2 A (at 120 V, AC15)

2 A (at 250 V, AC15)

General

Operating mode

100% operating factor

Degree of protection

RT III (Relay)

Mechanical service life

3 x 107 cycles

Inflammability class according to UL 94

Designation

Standards/regulations

IEC 60664

EN 50178

IEC 62103

Rated surge voltage / insulation

6 kV / Basic isolation

Pollution degree

Surge voltage category

III

Mounting position

any

Assembly instructions

In rows with zero spacing

Connection data

Connection method

Spring-cage connection

Stripping length

8 mm

Conductor cross section stranded min.

0.14 mm²

Conductor cross section stranded max.

2.5 mm²

Conductor cross section solid min.

0.14 mm²

Conductor cross section solid max.

2.5 mm²

Conductor cross section AWG/kcmil max

Conductor cross section AWG/kcmil min.

Classifications

eCl@ss

eCl@ss 4.0

27371102

eCl@ss 4.1

27371102

eCl@ss 5.0

27371001

eCl@ss 5.1

27371001

eCl@ss 6.0

27371001

eCl@ss 7.0

27371001

eCl@ss 8.0

27371001
