10/28/2014 Page 3 / 6

Relay Module - PLC-RSC- 60DC/21-21AU - 2967303

Technical data

Contact side

Switching capacity in acc. with DIN VDE 0660/IEC 60947

2 A (at 24 V, DC13)

0.2 A (at 110 V, DC13)

0.2 A (at 250 V, DC13)

2 A (at 24 V, AC15)

2 A (at 120 V, AC15)

2 A (at 250 V, AC15)

General

Test voltage relay winding/relay contact

4 kV AC (50 Hz, 1 min.)

Test voltage PDT/PDT

2.5 kV AC (50 Hz, 1 min.)

Operating mode

100% operating factor

Degree of protection

RT III (Relay)

Mechanical service life

3 x 107 cycles

Inflammability class according to UL 94

Designation

Standards/regulations

IEC 60664

EN 50178

IEC 62103

Rated surge voltage / insulation

6 kV / Basic isolation

Pollution degree

Surge voltage category

III

Mounting position

any

Assembly instructions

In rows with zero spacing

Connection data

Connection method

Screw connection

Stripping length

8 mm

Conductor cross section stranded min.

0.14 mm²

Conductor cross section stranded max.

2.5 mm²

Conductor cross section solid min.

0.14 mm²

Conductor cross section solid max.

2.5 mm²

Conductor cross section AWG/kcmil max

Conductor cross section AWG/kcmil min.

Screw thread
