3 / 13 page  UC621XX CMOS IC UNISONICTECHNOLOGIESCO.,LTD 3 of 13 www.unisonic.com.tw QW-R502-028.D ABSOLUTE MAXIMUM RATINGS (TA=25°C, Unless otherwise specified) PARAMETER SYMBOL RATINGS UNIT Input Voltage VIN 12 V Output Voltage VOUT Vss-0.3 ~ VIN+0.3 V CE Input Voltage VCE Vss-0.3 ~ VIN+0.3 V EXT Output Voltage VO(EXT) 12 V EXT Output Current IEXT 50 mA Power Dissipation PD 150 mW Junction Temperature TJ +125 °C Operating Temperature TOPR -40 ~ +85 °C Storage Temperature TSTG -40 ~ +150 °C Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. 2. The device is guaranteed to meet performance specification within 0°C ~+70°C operating temperature range and assured by design from -20°C ~+85°C. ELECTRICAL CHARACTERISTICS (TA=25°C, Unless otherwise specified) UC62130 ( VOUT(T) =3.0V) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT Output Voltage (Note2) VOUT(E) IOUT =50mA, VIN=4.0V 2.940 3.000 3.060 V Input Voltage VIN 8 V EXT Output Voltage VEXT 8 V CE Level Voltage High VCEH 1.5 V Low VCEL 0.25 V Load Stability (Note 4) △ VOUT VIN =4.0V, 1mA≤IOUT≤100mA -60 60 mV Input-Output Voltage Differential VDIFF IOUT =100mA 100 mV Maximum Output Current(Note 4) IOUT(MAX) VIN=4.0V 1000 mA Supply Current1 Iss1 VIN =4.0V, VCE =VSS 0.6 μA Supply Current2 Iss2 VIN =8.0V, VCE =VIN 50 80 μA EXT Leakage Current ILEAK 0.5 μA CE Level Current High ICEH VCE =VIN 0.1 μA Low ICEL VCE =VSS -0.2 -0.05 0 μA Input Stability (Note 4) △ VOUT △ VIN×VOUT IOUT =50mA, 4.0V≤VIN≤8.0V 0.1 0.3 %/V Output Voltage Temperature Characteristics (Note 4) △ VOUT △ TOPR×VOUT IOUT =10mA, -20°C ≤TOPR≤85°C ±100 ppm/°C UC62133 (VOUT(T)=3.3V) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT Output Voltage (Note2) VOUT(E) IOUT =50mA, VIN =4.3V 3.234 3.300 3.366 V Input Voltage VIN 8 V EXT Output Voltage VEXT 8 V CE Level Voltage High VCEH 1.5 V Low VCEL 0.25 V Load Stability (Note 4) △ VOUT VIN =4.3V, 1mA≤IOUT≤100mA -60 60 mV Input-Output Voltage Differential VDIFF IOUT =100mA 100 mV Maximum Output Current (Note 4) IOUT(MAX) VIN =4.3V 1000 mA Supply Current1 Iss1 VIN =4.3V, VCE =VSS 0.6 μA Supply Current2 Iss2 VIN =8.0V, VCE =VIN 50 80 μA EXT Leakage Current ILEAK 0.5 μA CE Level Current High ICEH VCE =VIN 0.1 μA Low ICEL VCE =VSS -0.2 -0.05 0 μA Input Stability (Note 4) △ VOUT △ VIN×VOUT IOUT =50mA, 4.3V≤VIN≤8.0V 0.1 0.3 %/V Output Voltage Temperature Characteristics (Note 4) △ VOUT △ TOPR×VOUT IOUT =10mA, -20°C ≤TOPR≤85°C ±100 ppm/°C |
|
|
