3 / 5 page ![]() P1484 LINEAR INTEGRATED CIRCUIT UNISONICTECHNOLOGIESCO.,LTD 3 of 5 www.unisonic.com.tw QW-R103-060.E ABSOLUTE MAXIMUM RATING (Note 1) PARAMETER SYMBOL RATINGS UNIT Supply Voltage VIN -0.3~+23 V Switch Node Voltage VSW 25 V All Other Pins -0.3~+6 V Continuous Power Dissipation (TA=25°C) (Note 2) PD 1.4 W Junction Temperature TJ 150 °C Storage Temperature TSTG -65~+150 °C Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. 2. The maximum allowable power dissipation is a function of the maximum junction temperature TJ (MAX), the junction-to-ambient thermal resistance θJA, and the ambient temperature TA. The maximum allowable continuous power dissipation at any ambient temperature is calculated by PD (MAX)=(TJ (MAX) - TA)/ θJA. Exceeding the maximum allowable power dissipation will cause excessive die temperature, and the regulator will go into thermal shutdown. Internal thermal shutdown circuitry protects the device from permanent damage. THERMAL DATA PARAMETER SYMBOL RATING UNIT Junction to Ambient θJA 90 °C/W Junction to Case θJC 45 °C/W Note: Measured on JESD5 1-7, 4-layer PCB RECOMMENDED OPERATING CONDITIONS PARAMETER SYMBOL RATING UNIT Input Voltage VIN 6~18 V Output Voltage VOUT 0.923~18 V Ambient Operating Temperature TOPR -40~+85 °C Note: The device is not guaranteed to function outside of its operating conditions. ELECTRICAL CHARACTERISTICS (VIN=12V, TA=+25°C, unless otherwise specified) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT Supply Current VEN=2.0V, VFB=1.0V 3.5 5 mA Feedback Voltage VFB 6V ≤VIN ≤23V 0.900 0.923 0.946 V High-Side Switch On Resistance (Note 1) RDS(ON)1 70 mΩ Low-Side Switch On Resistance (Note 1) RDS(ON)2 50 mΩ High-Side Switch Leakage Current VEN=0V, VSW=0V 10 μA Upper Switch Current Limit Minimum Duty Cycle 3.4 A Lower Switch Current Limit From Drain to Source 1.1 A COMP to Current Sense Transconductance GCS 5 A/V Oscillation Frequency FOSC1 300 365 430 KHz Short Circuit Oscillation Frequency FOSC2 VFB=0V 40 KHz Maximum Duty Cycle DMAX VFB=1.0V 92 % EN Shutdown Threshold Voltage VEN Rising 0.8 1.2 2.0 V Input Under Voltage Lockout Threshold VIN Rising 4 V Soft-Start Current VSS=0V 15 μA Thermal Shutdown (Note 1) 160 °C Note: Guaranteed by design, not tested. |
|
|
