V680 Series

Bolt RF Tags (1-kbyte Memory)

* Oil resistance has been tested using a specific oil as defined in the OMRON test method.

Bolt RF Tags (2-kbyte Memory)

*1 The number of accesses is the total number of communications for reading or writing.

*2 Oil resistance has been tested using a specific oil as defined in the OMRON test method.

Item

Model

V680-D1KP52M-BT01

V680-D1KP52M-BT11

Memory capacity

1,000 bytes (user area)

Memory type

EEPROM

Data retention time

10 years after writing (85°C or less), 0.5 years after writing (85 to 125°C)

Total data retention at high temperatures exceeding 125°C is 10 houres

Write endurance

100,000 times per block (at 25°C)

Ambient operating

temperature

(during communication)

−25 to 85°C (with no icing)

Ambient storage

temperature

(during data backup)

−40 to 125°C (with no icing)

Ambient operating

humidity

35 to 95%

Degree of

protection

IP68 (IEC 60529:2001)

Oil resistance equivalent to IP67G (JIS C 0920:2003, Appendix 1)

Vibration resistance 10 to 2,000 Hz, 1.5-mm double amplitude at 150 m/s2 acceleration with 10 sweeps in X, Y, and Z directions for 15 minutes each

Shock resistance

500 m/s2 in X, Y, and Z directions 3 times each (18 times in total)

Materials

Bolt: SUS303,

Case (RF Tag): PPS resin,

Filling (RF Tag): Epoxy resin

Weight

Approx. 25 g

Approx. 10 g

Item

Model

V680-D2KF52M-BT01

V680-D2KF52M-BT11

Memory capacity

2,000 bytes (user area)

Memory type

FRAM

Data retention time

10 years after writing (55°C or less), 2.9 years after writing (85°C max.)

Write endurance

10 billion reads/writes per block, Number of accesses

*1: 10 billion times

Ambient operating

temperature

(during communication)

−25°C to 85°C (with no icing)

Ambient storage

temperature

(during data backup)

−40°C to 85°C (with no icing)

Ambient operating

humidity

35 to 95%

Degree of

protection

IP67 (IEC 60529:2001)

Oil resistance equivalent to IP67G (JIS C 0920:2003, Appendix 1)

Vibration resistance 10 to 2,000 Hz, 1.5-mm double amplitude at 150 m/s2 acceleration with 10 sweeps in X, Y, and Z directions for 15 minutes each

Shock resistance

500 m/s2 in X, Y, and Z directions 3 times each (18 times in total)

Materials

Bolt: SUS303,

Case (RF Tag): PPS resin,

Filling (RF Tag): Epoxy resin

Weight

Approx. 25 g

Approx. 10 g
