CD4069L-S14-R Datasheet(PDF) 1 Page - Unisonic Technologies |
|
|
|||||||||||||||||||||||||||||
CD4069L-S14-R Datasheet(HTML) 1 Page - Unisonic Technologies |
|
|
1 / 7 page  UNI SONI C TECHNOLOGI ES CO., LTD CD4069 CMOS IC www.unisonic.com.tw 1 of 7 Copyright © 2017 Unisonic Technologies Co., Ltd QW-R502-020.E I N V ERT ER CI RCU I T S DESCRI PT I ON The UTC CD4069 consists of six inverter circuits and is manufactured using complementary MOS (CMOS) to achieve wide power supply operating range, low power consumption, high noise immunity, and symmetric controlled rise and fall times. All inputs are protected from damage due to static discharge by diode clamps to VDD and VSS. FEAT U RES * Wide supply voltage range: 3.0V ~ 15V. * High noise immunity: 0.45 VDD typ. * Low Power TTL compatibility: Fan out of 2 driving 74L or 1 driving 74LS. DIP-14 SOP-14 ORDERI N G I N FORM AT I ON Ordering Number Lead Free Halogen Free Package Packing CD4069L-D14-T CD4069G-D14-T DIP-14 Tube CD4069L-S14-R CD4069G-S14-R SOP-14 Tape Reel M ARK I N G DIP-14 SOP-14 |
