ST2001FX

2/7

THERMAL DATA

ELECTRICAL CHARACTERISTICS (Tj = 25 °C unless otherwise specified)

* Pulsed: Pulse duration = 300 µs, duty cycle = 1.5 %.

Rthj-case

Thermal Resistance Junction-case

Max

°C/W

Symbol

Parameter

Test Conditions

Min.

Typ.

Max.

Unit

ICES

Collector Cut-off

Current (VBE = 0)

VCE = 1500 V

Tj = 125 °C

IEBO

Emitter Cut-off Current

(IC = 0)

VEB = 7 V

VCEO(sus)* Collector-Emitter

Sustaining Voltage

(IB = 0)

IC = 100 mA

600

VCE(sat)*

Collector-Emitter

Saturation Voltage

IC = 5 A

IB = 1.25 A

1.5

VBE(sat)*

Base-Emitter

Saturation Voltage

IC = 5 A

IB = 1.25 A

1.2

hFE*

DC Current Gain

IC = 6 A

VCE = 1 V

VCE = 5 V

4.5

INDUCTIVE LOAD

Storage Time

Fall Time

IC = 5 A

IBon (END) = 850 mA

LBB(off) = 2 µH

VBB(off) = -2.5 V

fh = 64 KHz

(See Figure 1)

2.6

0.2

0.4

µs
