ORDERING INFORMATION TABLE

1

2

D = Standard recovery device

3

None = Stud normal polarity (cathode to stud)

4

R = Stud reverse polarity (anode to stud)

Device code

D

M

85

R

12

1

2

3

4

5

5

Voltage code × 100 = V

(see Voltage Ratings table)

RRM

None = Stud base DO-203AB (DO-5) 1/4”-28 UNF-2A, standard type

M = Stud base DO-203AB (DO-5) M6×1.0, standard type

DO-203AB(DO-5), standard type

19(0.75)

Ø15.2(Ø0.598) Max

(0.24/0.28)

6.2/7.0

Ø4.0(Ø0.157)

1/4” 28UNF-2A

For metric devices: M6x1.0

(0.028/0.043)

0.7/1.1

AII dimensions in millimeters (inches)

Glass-Metal Seal

-

-

-

-

-

S = Stud base DO-203AB (DO-5) M8×1.0, “Semikron” type

RoHS

RoHS
