FP1007R6-R15-R Datasheet(PDF) 3 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
FP1007R6-R15-R Datasheet(HTML) 3 Page - Eaton All Rights Reserved. |
|
|
3 / 4 page  3 www.eaton.com/electronics Technical Data 10007 Effective June 2017 Core loss vs Bp-p Inductance characteristics FP1007R6 High frequency, high current power inductor Temperature rise vs total loss 1MHz 500kHz 10 300kHz 200kHz 1 100kHz 0.1 0.01 0.001 0.0001 0.00001 100 1000 10000 Bp-p (Gauss) % of OCL vs. Isat1 100% 80% 60% 40% -40°C +100°C +25°C 20% 0% 0% 20% 40% 60% 80% 100% 120% 140% 160% % of Isat1 60 50 40 30 20 10 0 0.0 0.4 0.8 1.2 1.6 2.0 Total Loss (W) |
|
|
