background image
Technical Data 10476
Effective November 2015
FP1108B
High frequency, high current power inductors
Product description
•
High current carrying capacity
•
Low core loss
•
Tight tolerance DCR for sensing circuits
•
11.6 x 8.0mm footprint surface mount package
in 8.0mm height
•
Ferrite core material
•
Halogen free, lead free, RoHS compliant
Applications
•
Servers
•
Multi-phase and Vcore regulators
•
Voltage Regulator Modules (VRMs)
•
Server and desktop
•
Central processing unit (CPU)
•
Graphics processing unit (GPU)
•
Application specific integrated circuit (ASIC)
•
High power density
•
Data centers, networking and storage systems
•
Point-of-Load modules
•
DCR Sensing circuits
Environmental data
•
Storage temperature range (Component):
-40°C to +125°C
•
Operating temperature range: -40°C to +125°C
(ambient + self-temperature rise)
•
Solder reflow temperature:
J-STD-020D compliant
Pb
HALOGEN
HF
FREE
