3 / 4 page  3 www.eaton.com/electronics Technical Data 4342 Effective June 2017 Core loss vs Bp-p Inductance characteristics FP1107 High frequency, high current power inductor Temperature rise vs total loss 80 60 40 20 FP1107R 1 FP1107R 2 0 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 2.2 2.4 T otal Loss (W) 1MHz 10 500kHz 300kHz 200kHz 1 100kHz 0.1 0.01 0.001 100 1000 10000 Bp-p (Ga uss) % of O C L vs % of Isat1 100% -40°C 80% +25°C 60% 40% +125°C 20% 0% 0% 20% 40% 60% 80% 100% 120% 140% % of Isat1 |
|
|
