FP1208R1-R23-R Datasheet(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
FP1208R1-R23-R Datasheet(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 4 page  Technical Data 10148 Effective June 2017 Supersedes August 2013 Product features • 12.1x8.0x8.0mm maximum surface mount package • Ferrite core material • Controlled DCR for sensing circuits • Inductance range from 150nH to 250nH • Current range from 44 to 85 Amps • Halogen free, lead free, RoHS compliant Applications • Storage temperature range (component): -40 °C to +125 °C • Operating temperature range: -40 °C to +125 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant FP1208 High frequency, high current power inductors Pb HALOGEN HF FREE • Multi-phase regulators • Voltage Regulator Modules (VRMs) • Desktop and server VRMs and EVRDs • Data networking and storage systems • Graphics cards and battery power systems • Point-of-Load modules • DCR Sensing circuits Environmental data |
