4 / 5 page  4 Technical Data 10477 Effective November 2015 FP1309B High frequency, high current power inductors www.eaton.com/elx Core loss vs. B p-p Inductance characteristics 0% 20% 40% 60% 80% 100% 120% 020406080100 120140 160 FP1309B1-R120-R -40°C +125°C +100°C +25°C 0% 20% 40% 60% 80% 100% 120% 020406080100 120140 160 IDC (Amps) FP1309B1-R100-R -40°C +125°C +100°C +25°C IDC (Amps) 0% 20% 40% 60% 80% 100% 120% 020406080100 120140 FP1309B1-R150-R -40°C +125°C +100°C +25°C IDC (Amps) 0.001 0.01 0.1 1 10 100100010000 Bp-p (Gauss) FP1309B1 300kHz 500kHz 800kHz 1MHz |
|
|
