MS-02W

AT MARK SENSOR

series

MS-02W

series

AT MARK SENSOR

HIGH SPEED RESPONSE 5 Khz

EASY TO SET OPTIMUN DETECTING

STATUS WITH SENSITIVITY &

EMITTING AUTOTUNNING

WHITE LIGHT EMITTER EASY TO DETECT

THE RED OR GREEN MARK

CO-AXIAL DETECTER DETECTS THE MARK

MORE STABLE

DARK ON/LIGHT ON CHANGEABLE

NPN & PNP TWO OUTPUT

Specification

Type

Model

Setting distance

Emitter

Light spot

Operating voltage

Current consumption

Output method

Output status

Output current

Leakage current

Residual voltage

Protection circuit

Illumination

Connection method

Housing material

Protection class

Circumstance

Response time

MS-02W

MS-O2W-H

MS-02W-M12

MS-02W-H-M12

LEAD WIRE

M12 CONNECTER

M12 x 1.0

Lamplight <5,000Lux; Sunlight < 10,000Lux

10-30 VDC;Ripple < 20% of peak to peak

150 mA max.

Short Circuit & Polarity Reversed Protection

0.2 mS

0.1 mS

0.2 mS

0.1 mS

25.0 2.0 mm

40 mA max.

NPN & PNP two output

NO or NC Changeable

White Light Led

0.8 mA max.

0.8 V max.

Intensive PBT

Ip-65

-20

+ 60

; 35%

85 % RH
