TECHNICAL DATA SHEET
产品数据表
TE-R8-4 XXXX
<FOR COB MODULE>
1 / 12
PREPARED BY：Lisa.y
TE-R8
SERIES
A/3
Revision issued in 2014.
1. PRODUCT APPEARANCE
产品实物图
2. OUTLINE DRAWING
外形尺寸图
3. SCHEMATIC DIAGRAM
原理图
13.35
1.22
2.60
Φ
7.5
1.00±0.05
0.60±0.1
Unit：mm
Tolerance：±0.25
X12
V-
X12
V+
