FUZETEC TECHNOLOGY CO., LTD.

NO.

PQ04-01ER

Product Specification and Approval Sheet Version B1

Page

4/5

NOTE : Specification subject to change without notice.

2017/9/13

110

7. Material Specification

Terminal pad material: Pure Tin

Soldering characteristics: Meets EIA specification RS 186-9E, ANSI/J-std-002 Category 3

8. Part Numbering and Marking System

Part Numbering System

Part Marking System

F S M D □ □ □ – R

F S M D □ □ □ – □ □ – R

Warning: -Operation beyond the specified maximum ratings or improper use may result in damage and possible

electrical arcing and/or flame.

-PPTC device are intended for occasional overcurrent protection. Application for repeated overcurrent

condition and/or prolonged trip are not anticipated.

-Avoid contact of PPTC device with chemical solvent. Prolonged contact will damage the device

performance.

Fuzetec Logo

F □ □ □

Part Identification

F110

Example

Current Rating

Voltage Rating

□ □ □

□ □

Part Identification

Fuzetec Logo

Example
