Technical Information

Product

Title

NLT4MP

Connection Type

speakON

Gender

male

Electrical

Contact resistance

< 2 mΩ (after lifetime)

Dielectric strength

4 kVdc (peak)

Insulation resistance

> 10 GΩ

Rated current per contact

40 A rms continuous

Rated current per contact

50 A audiosignal, duty cycle 50 %

Rated voltage

250 V ac

Attention

speakON is NOT to be used as an AC mains or power supply

connector!

Mechanical

Lifetime

> 5000 mating cycles

Wiresize

Locking device

Quick Lock

Chassis shape

square G-size flange

Layout

four thru holes

Material

Contact plating

4 µm Ag

Insert

Polyamide (PA 6 30 % GR)

Shell

Zinc diecast (ZnAl4Cu1) Ni

Contacts

Spring Copper (CuSn0.2)

NLT4MP

2
