Product description

• High current carrying capacity

• Magnetically shielded, low EMI

• Frequency range up to 1MHz

• Inductance range from 1.5μH to 68.0μH

• Current range from 5.2 to 40.0 amps

• 17.5x17.2mm footprint surface mount

package in a 7.0mm height

• Powder iron core material

• Halogen free, lead free, RoHS compliant

Applications

• Voltage Regulator Module (VRM)

• Multi-phase regulators

• Point-of-load modules

• Desktop and server VRMs and EVRDs

• Data networking and storage systems

• Base station equipment

• Battery power systems

Environmental data

• Storage temperature range (Component):

-55°C to +125°C

• Operating temperature range: -55°C to +125°C

(ambient + self-temperature rise)

• Solder reflow temperature: J-STD-020D

compliant

Coiltronics HCM1707 Series

High current power inductors

Technical Data 10295

Effective August 2014

Coiltronics is now

part of Eaton

Same great

products plus

even more.

The Coiltronics brand of

magnetics (formerly of

the Bussmann Division of

Cooper Industries)

is now part of

Eaton’s Electrical Group,

Electronics Division.
