DOCUMENT : CYNP-199-032

Page : 3

REVISION

: A1

Current Sensor Resistor

Type Designation :

S C M M

2512

S

2

ー

□ □ □ □

□

(1)

(2)

(3)

(4)

(5)

(6)

P/N list :

P/N

R value

TCR

Power Rating

Tolerance

(mΩ)

(ppm/K)

(W)

1%

2%

5%

SCMM2512S2-0M30*

0.3

±100

2



SCMM2512S2-0M50*

0.5

±75

2



SCMM2512S2-0M75*

0.75

±75

2



SCMM2512S2-0M80*

0.8

±75

2



SCMM2512S2-R001*

1.0

±50

2



SCMM2512S2-R002*

2.0

±50

2



SCMM2512S2-R003*

3.0

±50

2



SCMM2512S2-R004*

4.0

±50

2



SCMM2512S2-R005*

5.0

±50

2



SCMM2512S2-R006*

6.0

±50

2



SCMM2512S2-R007*

7.0

±50

2



SCMM2512S2-R008*

8.0

±50

2



SCMM2512S2-R009*

9.0

±50

2



SCMM2512S2-R010*

10.0

±50

2



SCMM2512S2-R015*

15.0

±50

2



SCMM2512S2-R020*

20.0

±50

2



* Note : Other values and tolerance would be available, please contact Cyntec.

Note :

(1) Series No.

(2) Size

(3) Terminal Type : S = Short terminal

(4) Power Rating : 2 = 2W

(5) Resistance value : R003 = 0.003, 0M50 = 0.0005

(6) Tolerance : F = ±1%, G = ±2%, J = ±5%
