CS7N65A3-R Datasheet(PDF) 1 Page - DONGGUAN YOU FENG WEI ELECTRONICS CO., LTD |
|
|
|||||||||||||||||||||||||||||
CS7N65A3-R Datasheet(HTML) 1 Page - DONGGUAN YOU FENG WEI ELECTRONICS CO., LTD |
|
|
1 / 6 page  N-CHANNEL MOSFET CS7N65A 1 / 6 www.yfwdiode.com Dongguan YFW Electronics Co, Ltd. N-CHANNEL ENHANCEMENT MODE POWER MOSFET MAIN CHARACTERISTICS ID 7A VDSS 650V RDSON-typ(@VGS=10V) 1.06 Ω FEATURES Fast Switching Low ON Resistance Low Gate Charge 100% Single Pulse avalanche energy Test Lead free in comply with EU RoHS 2011/65/EU directives MECHANICAL DATA Case: Molded plastic Mounting Position: Any Molded Plastic: UL Flammability Classification Rating 94V-0 Solder bath temperature275℃maximum,10s per JESD22-106 Case: TO-220AB TO-220F TO-263 TO-252 TO-251 PRODUCT SPECIFICATION CLASSIFICATION Part Number Package Mode Name Pack CS7N65A1 TO-220AB CS7N65A Tube CS7N65A2 TO-220F(0.5mm) CS7N65A Tube CS7N65A3 TO-263 CS7N65A Tube CS7N65A3-R TO-263 CS7N65A Tape CS7N65A4 TO-251 CS7N65A Tube CS7N65A5-R TO-252 CS7N65A Tape |
