Operating Humidity:

0%

–90%, non-condensing

Operating Temperature:

0°C

– 45°C (32°F – 113°F)

Storage:

-40°C

–65°C (-40°F–149°F)

EMC Certifications:

FCC Part 15, Subpart B Class A

Conducted Emissions

Radiated Emissions

CE EN 55022: 1998 Class A Amendments A1: 2000; A2: 2003

Conducted Emissions

Radiated Emissions

CE EN 55024: 1998 Amendments A1: 2000; A2: 2003

Immunity for ITE Amendment A1: 2001

CE EN 61000-3-2 2000, Class A

Harmonic Current Emissions

CE EN 61000 3-3 1995, Amendment A1: 2001

Voltage Fluctuations and Flicker

CE IEC 6100-4-2: 1995

ESD Air Discharge 8kV. Contact Discharge 4kV

CE IEC 6100-4-3:1995

Radiated Immunity (80-1000Mhz), 3V/m 80% A.M. by 1kHz

CE IEC 6100-4-4:1995

EFT/B: Immunity to electrical fast transients 1kV Power

Leads, 0.5Kv Signals Leads

CE IEC 6100-4-5:1995

Immunity to conductive surges COM Mode; 2kV,

Dif. Mode 1kV

CE IEC 6100-4-6:1996

Conducted immunity (0.15-80 MHz) 3VRMS 80% A.M.

By 1kHz

CE IEC 6100-4-11:1994

Voltage Dips and Short Interruptions

V reduc >95%, 30% >95% Duration 0.5per, 25per, 250per

MTBF:

211 (Years)

* According to Telcordia SR-332 Issue 2. Environmental condition

– GB (Ground, Fixed, and

Controlled). Ambient temperature 40°C

LEDs

LEDs:

2 LEDs per port

Left LED : Link:

Turns on Yellow Any Speed Link.

Right LED: Link/Act :
