Board Size:

Low profile long add-

in card: 302.36mm X 68.91mm (7.68” X 2.713”)

PCI Express Card Type:

X8 Lane

PCI Express Voltage:

+12V +- 8%

PCI Connector:

X8 Lane

Controller:

8 x Cavium CN1620

Holder:

Metal Bracket

Weight:

280 gram (9.877 oz)

Power Consumption:

17.4W, 1.45A- without load

35.88W, 2.99A- full load state

Operating Temperature:

0°C

– 55°C (32°F – 131°F)

Air-Flow: 650 ft/sec

Storage:

-40°C

–65°C (-40°F–149°F)

EMC Certifications:

FCC Part 15, Subpart B Class A

Conducted Emissions

Radiated EmissionsB Class B

CE EN 55022: 1998 Class A Amendments A1: 2000; A2: 2003

Conducted Emissions

Radiated Emissions

CE EN 55024: 1998 Amendments A1: 2000; A2: 2003

Immunity for ITE Amendment A1: 2001

CE EN 61000-3-2 2000, Class A

Harmonic Current Emissions

CE EN 61000 3-3 1995, Amendment A1: 2001

Voltage Fluctuations and Flicker

CE IEC 6100-4-2: 1995

ESD Air Discharge 8kV. Contact Discharge 4kV.

CE IEC 6100-4-3:1995

Radiated Immunity (80-1000Mhz), 3V/m 80% A.M. by 1kHz

CE IEC 6100-4-4:1995

EFT/B: Immunity to electrical fast transients 1kV Power

Leads, 0.5Kv Signals Leads

CE IEC 6100-4-5:1995

Immunity to conductive surges COM Mode; 2kV,

Dif. Mode 1kV
