ADL8150
Data Sheet
Rev. 0 | Page 4 of 15
FREQUENCY RANGE: 12 GHz TO 14 GHz
VCC = 5 V, ICQ = 74 mA and TA = 25°C, unless otherwise noted.
Table 3.
Parameter
Min
Typ
Max
Unit
Test Conditions/Comments
FREQUENCY RANGE
12
14
GHz
GAIN
8
10.5
dB
Gain Flatness
±0.9
dB
Gain Variation over Temperature
0.034
dB/°C
NOISE FIGURE
3.8
dB
PHASE NOISE
−172
dBc/Hz
Measurement taken at 10 kHz offset from carrier
RETURN LOSS
Input
5
dB
Output
8
dB
OUTPUT
OP1dB
15.5
17.5
dBm
PSAT
21.5
dBm
OIP3
30
dBm
Measurement taken at POUT per tone = 6 dBm
OIP2
60
Measurement taken at POUT per tone = 6 dBm
SUPPLY
ICQ
74
mA
Self biased
VCC
3
5
6
V
