MODEL: M6SXAT

M6SXAT SPECIFICATIONS

ES-7992 Rev.4 Page 4/5

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

5.9 (.23)

DIN RAIL

35mm wide

DIN RAIL HOOK

*Use a minus screwdriver: tip width 3.8 mm max., tip thickness 0.5 to 0.6 mm

102 (4.02)

[0.5 (.02)]

SCREWDRIVER

INSERTION ANGLE

: approx. 40°

WIRE INSERTION ANGLE

: approx.35°

TEST PROBE

max. 2 (.08) dia.

SCREWDRIVER *

INSERTION ANGLE

: approx. 35°

5

6

7

8

1

2

3

4

• When mounting, no extra space is needed between units.

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Low Drift

Amplifier

7

8

1

2

4

3

NC

NO

COM

+

-

5

6

■ Relay Protection

• AC Powered

• DC Powered

POWER

+

–

OUTPUT

Ry

CONFIGURATOR

JACK

STATUS

LED

ALARM

MONITOR LED

Digital

Computation

+

–

T/C

comp. leadwire

CJC

SENSOR

POWER

POWER LED

Varistor or CR Circuit

Diode, Varistor or

CR Circuit

LOAD

Inductive

Load (Coil)

U

LOAD

Inductive

Load (Coil)
