MODEL: M6SXF3

M6SXF3 SPECIFICATIONS

ES-7990 Rev.4 Page 4/5

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

5.9 (.23)

DIN RAIL

35mm wide

DIN RAIL HOOK

*Use a minus screwdriver: tip width 3.8 mm max., tip thickness 0.5 to 0.6 mm

102 (4.02)

[0.5 (.02)]

SCREWDRIVER

INSERTION ANGLE

: approx. 40°

WIRE INSERTION ANGLE

: approx.35°

TEST PROBE

max. 2 (.08) dia.

SCREWDRIVER *

INSERTION ANGLE

: approx. 35°

5

6

7

8

1

2

3

4

• When mounting, no extra space is needed between units.

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

+

–

+

–

CONFIGURATOR

OUTPUT

7

8

1

2

5

6

POWER

CONTROL

JACK

Digital

Computation

INPUT

3

4

3 kΩ

+3 V

POWER

POWER LED

Isolation

Low Drift

Amplifier

Output

Driver

DIP SW

24.9 Ω

STATUS

IND. LED
