MODEL: M8YV1

M8YV1 SPECIFICATIONS

ES-5389 Rev.4 Page 2/3

http://www.m-system.co.jp/

Zero adjustment: -2 to +2 % (front)

(±1 % with the input suffix codes 4W and 5W selected)

Span adjustment: 98 to 102 % (front)

(99 to 101 % with the input suffix codes 4W and 5W

selected.)

INPUT SPECIFICATIONS

■ DC Current: Input resistor incorporated

Specify input resistance value for code Z.

(R ≤ 0.25 W ÷ [F.S. Current]2)

■ DC Voltage: -10 – +10 V DC

Minimum span: 1 V

Offset: Max. 1.5 times span

Input resistance: 1 MΩ min.

(10 kΩ min. at loss of power)

INSTALLATION

Current consumption: Approx. 20 mA (40 mA for current

output)

Operating temperature: 0 to 55°C (32 to 131°F)

Operating humidity: 30 to 95 %RH (non-condensing)

Mounting: Installation Base (model: M8BSx)

Weight: 70 g (2.5 oz)

PERFORMANCE in percentage of span

Accuracy: ±0.1 %

Temp. coefficient: ±0.02 %/°C (±0.01 %/°F)

Line voltage effect: ±0.1 % over voltage range

Insulation resistance: ≥ 100 MΩ with 500 V DC

Dielectric strength:

1500 V AC @1 minute (input to output 1 or output 2 or

power to ground)

500 V AC @1 minute (output 1 to output 2 to power)

SWC test: ANSI/IEEE-C37.90.1-1989

STANDARDS & APPROVALS

EU conformity:

EMC Directive

EMI EN 61000-6-4

EMS EN 61000-6-2

RoHS Directive

EN 50581
