MODEL: W2DY

W2DY SPECIFICATIONS

ES-5526 Rev.14 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

4

8 7

10

21.5 (.87)

84 (3.31)

10 (.39)

22 (.87)

DIN RAIL

35mm wide

[4 (.16)]

SCREW

29.5 (1.16)

(.17x.20)

MTG HOLE

6 (.24) deep

114 (4.49)

11

5

6

1

2

3

9

6 (.23)

• When mounting, no extra space is needed between units.

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Base Socket

4

Low Drift

Amplifier

50Ω

250Ω

+

–

+

–

2

5

1

2-WIRE

TRANSMITTER

–

+

MONITOR

(1 – 5V DC)

V

9

Current

Limiter

U(+)

V(–)

POWER

10

11

+

–

OUTPUT 1

+

–

Isolation

S

Z

Output

Driver

S

Z

Output

Driver

OUTPUT 2

7

8

3

6

Note: The section enclosed by broken line is only with 2nd output option.

Specifications are subject to change without notice.
