MODEL: JC-CU

JC-CU SPECIFICATIONS

ES-9042 Rev.2 Page 2/9

https://www.m-system.co.jp/

Number of inserted HUBs

Transfer rate

12Mbps

100m

200m

300m

6Mbps

200m

400m

800m

3Mbps

300m

600m

900m

INSTALLATION

Rated current for power supply connector: 8A

Power consumtpion:

JC-CU-3: Approx. 0.9 W

JC-CU-7: Approx. 1.2 W

Operating temperature: -10 to +55°C

Operating humidity: 10 to 90 %RH (non-condensing)

Atmosphere: No corrosive gas or heavy dust

Mounting: Surface or DIN rail

Weight

JC-CU-3: 150 g (0.33 lb)

JC-CU-7: 160 g (0.35 lb)

PERFORMANCE

Insulation resistance: ≥ 100 MΩ with 500 V DC

JC-CU-3 (CU0A or CU0B to CU1 or CU2 or FE to power)

JC-CU-7 (CU0A or CU0B to CU1 or CU2 or CU3 or CU4 or CU5

or CU6 or FE to power)

Dielectric strength: 1500 V AC @ 1 minute

JC-CU-3 (CU0A or CU0B to CU1 or CU2 or FE to power)

JC-CU-7 (CU0A or CU0B to CU1 or CU2 or CU3 or CU4 or CU5

or CU6 or FE to power)

STANDARDS & APPROVALS

Refer to the manuals to comply with the standards.

EU conformity:

EMC Directive

EMI EN 61000-6-4

EMS EN 61000-6-2

RoHS Directive
