MODEL: JC-CU

JC-CU SPECIFICATIONS

ES-9042 Rev.2 Page 5/9

https://www.m-system.co.jp/

■ CONNECTION WITH OTHERS

CUnet I/O Module

CUnet I/O Module

CUnet I/O Module

HUB Module

Trunk CU0A/CU0B

Feeder CU1 – CU6

TR+

TR−

SLD

TR+

TR−

SLD

TR+

TR−

SHIELD

TR+

TR−

SLD

TR+

TR−

SLD

Terminating

Resistor

Terminating

Resistor

Terminating

Resistor

Terminating

Resistor

Note: Be sure to turn ON the switch of the terminating resistor located at both ends of the modules.

DIMENSIONS unit: mm (inch)

50(1.97)

[3(.12)]

[4(.16)]

73(2.87)

55(2.17)

DIN RAIL

(35 mm wide)

2–4.3 (.17) dia Mtg Hole

4 (.16) deep
