MODEL: KEWT

KEWT SPECIFICATIONS

ES-3666 Rev.6 Page 6/6

http://www.m-system.co.jp/

CUSTOM SPECIFICATION : OPTION /X1

Major specification changes

Input 0%: -65 - 0 % of input 100% (W)

MODEL: KEWT–[1][2][3]-[4][5]

Same as standard specification (without customization)

except followings.

Refer to standard specification pages.

ORDERING INFORMATION

• Code number: KEWT–[1][2][3]-[4][5]

For each of [1] through [5] same code as standard

specification is available.

Be sure to specify /X1 of option [5].

(e.g. KEWT-11A-C/X1/Q)

Refer to standard specification pages.

SPECIFICATION CHANGES

■ Input specifications

• Available input range

The value for 0% is within -65 - 0 % of input 100%.

e.g. Input range: -75 to 1000 [W]

-75 [W] ÷ 1000 [W] × 100 = -7.5 [%]

-75

+1000 W

-1000

+1000 W

-1000

-10

■ OPERATION DIAGRAM (example)

20 mA

OUTPUT

INPUT

+10 V

OUTPUT

INPUT
