MODEL: KSL

KSL SPECIFICATIONS

ES-3613 Rev.10 Page 3/5

http://www.m-system.co.jp/

EXTERNAL VIEW

Lo LED

Lo Setpoint Rotary Switch (×1%)

Lo Setpoint Rotary Switch (×10%)

Hi Setpoint Rotary Switch (×1%)

Hi Setpoint Rotary Switch (×10%)

Hi LED

HI SET

[%]

x1

x10

LO SET

[%]

x1

x10

EXTERNAL DIMENSIONS unit: mm (inch)

■OUTPUT CODE: 2, 3

3

4

5

6

2

1

8

7

50 (1.97)

103 (4.06)

123 (4.84)

[3.3 (.13)]

40 (1.57)

50 (1.97)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

MTG HOLE

15 (.59) deep

SCREW

• When mounting, no extra space is needed between units.

■OUTPUT CODE: 5

50 (1.97)

103 (4.06)

132 (5.20)

• When mounting, no extra space is needed between units.

5

6

7

8

2

1

11

10

[3.3 (.13)]

40 (1.57)

50 (1.97)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

MTG HOLE

25 (.98) deep

SCREW

3

9

4
