MODEL: 48NAT

48NAT SPECIFICATIONS

ES-9433 Rev.13 Page 7/9

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

75 (2.95)

103 (4.06)

10 (.39)

18

(.71)

1

3

5

6

7

8

9

10

11

12

13

14

15

16

16–M3 SCREW

TERMINALS

2–M3 SCREWS

CJC SENSOR

(CJM)

36 (1.42)

31 (1.22)

0.5 (.02)

2

4

Rounded corners for the option /D

■ OPTION /D BEZEL*

3

*1. Space required when replacing the scale plate.

*2. Used for the existing panel cutout of M-System 48 Series (38 × 139.5 mm).

*3. Used for the existing DIN panel cutout (33 × 138 mm)

*4. Used for the existing panel cutout of Fuji Electric PAJ, PAK, PBA (44 × 138 mm), etc.

■ STANDARD BEZEL*

2

10.4

(.41)

7.5

(.30)

3.9

(.15)

11.4

(.45)

7.5

(.30)

4.9

(.19)

8.5

(.33)

10.4

(.41)

7.5

(.30)

■ OPTION /F BEZEL*

4
