SMD POWER INDUCTORS

1 Excellent Power Density

2 Engineered to Provide High Efficiency

ELECTRICAL CHARACTERISTICS

Part Number

Inductance

(uH)

(1)

Test

Frequency

DC Resistance

(

Ω MAX)

(2)

Saturation

Current

(A)

Temperature

Current

(A)

SCEP105S-R22

0.22

100KHZ

2.6m

40.0

20.0

SCEP105S-R45

0.45

100KHZ

3.2m

26.4

18.0

SCEP105S-R80

0.8

100KHZ

4.1m

20.8

14.0

SCEP105S-1R3

1.3

100KHZ

5.3m

16.8

13.0

SCEP105S-1R8

1.8

100KHZ

8.0m

13.8

11.5

SCEP105S-2R5

2.5

100KHZ

10.5m

11.8

9.00

SCEP105S-3R2

3.2

100KHZ

12.4m

10.5

8.00

SCEP105S-4R0

4.0

100KHZ

18.0m

9.3

7.50

SCEP105S-5R0

5.0

100KHZ

23.8m

8.4

6.65

(1). Inductance tolerance for 0.22uH:

±30%, for 0.45uH~5.0uH: ±20%. Tested at 0.25V, 0ADC and 25℃

(2). DCR measured at 25

℃.

(3). The DC current at which the inductance decreases by 25% from its initial value.

(4). The DC current that results in a 40

℃ temperature rise from 25℃ambient.
