MODEL: MUWT

MUWT SPECIFICATIONS

ES-1926 Rev.3 Page 5/5

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

72 (2.83)

109 (4.29)

139 (5.47)

[3.3 (.13)]

60 (2.36)

72 (2.83)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

2–4.5 (.18) dia.

MTG HOLE

25 (.98) deep

14–M3.5

SCREW

•When mounting, no extra space is needed between units.

12

5

6

14

1

10

4

3

7

8

CT PROTECTOR

(model: CTM)

1

2

1

MUWT-2

2

MUWT-1, 3

1

Positions of CTM

9

15

11 2
