MODEL: R30MS4

R30MS4 SPECIFICATIONS

ES-9004 Rev.3 Page 4/5

https://www.m-system.co.jp/

TERMINAL ASSIGNMENTS

11

NC

12

L1

13

NC

14

L2

15

NC

16

NC

17

L3

18

NC

19

L4

20

NC

1

H1

2

S1

3

H2

4

S2

5

NC

6

H3

7

S3

8

H4

9

S4

10

NC

NO.

ID

FUNCTION

NO.

ID

FUNCTION

1

H1

Pot 1-H

11

NC

No connection

2

S1

Pot 1-S

12

L1

Pot 1-L

3

H2

Pot 2-H

13

NC

No connection

4

S2

Pot 2-S

14

L2

Pot 2-L

5

NC

No connection

15

NC

No connection

6

H3

Pot 3-H

16

NC

No connection

7

S3

Pot 3-S

17

L3

Pot 3-L

8

H4

Pot 4-H

18

NC

No connection

9

S4

Pot 4-S

19

L4

Pot 4-L

10

NC

No connection

20

NC

No connection

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm [inch]

①

②

③

④

⑪

⑫

⑬

⑭ ⑤

⑥

⑦

⑧

⑨

⑩

⑮

⑯

⑰

⑱

⑲

⑳

25 [.98]

98 [3.86]

20–M3

SCREW
