HMC8191

Data Sheet

Rev. C | Page 4 of 44

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

RF Input Power

24 dBm

LO Input Power

24 dBm

IF Input Power

24 dBm

IF Source/Sink Current

3 mA

Continuous Power Dissipation, PDISS

(TA = 85°C, Derate 7.29 mW/°C Above 85°C)

657 mW

Maximum Junction Temperature

175°C

Maximum Peak Reflow Temperature (MLS3)

260°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Electrostatic Discharge Sensitivity

Human Body Model

750 V

Field Induced Charged Device Model

1200 V

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

Thermal performance is directly linked to PCB design and

operating environment. Careful attention to PCB thermal

design is required.

Table 3. Thermal Resistance

Package Type

θJA

θJC

Unit

E-24-11

38.3

137

°C/W

Refer to JDEC standard JESD51-2 for additional information on optimizing

the thermal impedance (PCB with 4 × 4 vias).

ESD CAUTION
