3 / 17 page

MODEL: SML

SML SPECIFICATIONS

ES-6371 Rev.4 Page 3/17

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

50 (1.97)

72 (2.83)

[3.3 (.13)]

60 (2.36)

72 (2.83)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

2–4.5 (.18) dia.

MTG HOLE

25 (.98) deep

14–M3.5

SCREW

• When mounting, no extra space is needed between units.

103 (4.06)

132 (5.20)

38 (1.50)

min.

(.39)

■ OTHER THAN SML-R2

72 (2.83)

38 (1.50)

139 (5.47)

109 (4.29)

[3.3 (.13)]

(top & bottom)

CLAMP

DIN RAIL

35mm wide

2–4.5 (.18) dia.

MTG HOLE

25 (.98) deep

14–M3.5

SCREW

7.8 (.31)

60 (2.36)

72 (2.83)

• When mounting, no extra space is needed between units.

(.39)

min.

■ SML-R2
