ø22mm - TW Series

Switches & Pilot Devices

732

www.IDEC.com

1904032203

Dimensions continued

Pilot Lights

Round Flush APW1 Full Voltage

Round Flush APW1 Transformer

29.6

17.2

28.5

34.3

ø23.6

Terminal cover

APS-PVL (supplied)

Panel thickness 1 to 6

17.2

59.5

29.6

ø23.6

M3.5

Terminal Screws

T transformer

Panel thickness 1 to 6

Round Flush Marking Type APW1B Full Voltage

Round Flush Marking Type APW1B Transformer

17.2

69.5

29.6

ø23.6

Panel thickness 1 to 6

M3.5 Terminal Screws

17.2

69.5

29.6

ø23.6

Panel thickness 1 to 6

M3.5 Terminal Screws

Dome APW2 Full Voltage

Dome APW2 Transformer

29.6

24.5

28.5

34.3

ø23.6

Terminal Cover

APS-PVL (supplied)

Panel thickness 1 to 6

24.5

59.5

29.6

ø23.6

M3.5

Terminal Screws

T transformer

Panel thickness 1 to 6

Square Flush Marking Type APQW1B Full Voltage

Square Flush Marking Type APQW1B Transformer

29.6

13.1

28.5

34.3



24.7

Panel thickness 1 to 6

Terminal cover

APS-PVL (supplied)

13.1

69.5

29.6

28.5

M3.5 Terminal Screws



24.7

Panel thickness 1 to 6

Illuminated Selector Switches

49.4 (1 block)

69.4 (2-3 blocks)

29.6

89.4 (4blocks)

ø23.4

Panel thickness 1 to 6

Adust ring
