ANT-W63-MON-RPS Datasheet(PDF) 1 Page - Linx Technologies |
|
|
|||||||||||||||||||||||||||||
ANT-W63-MON-RPS Datasheet(HTML) 1 Page - Linx Technologies |
|
|
1 / 24 page  Datasheet ANT-W63-MON-ccc WiFi 6 Monopole Whip Antenna Ordering Information Part Number Description ANT-W63-MON-RPS WiFi 6/WiFi 6E monopole whip antenna with RP-SMA plug (female socket) ANT-W63-MON-SMA WiFi 6/WiFi 6E monopole whip antenna with SMA plug (male pin) Available from Linx Technologies and select distributors and representatives. The Linx ANT-W63-MON series antenna is a compact monopole tilt/swivel whip antenna designed for superior performance in the 2.4 GHz, 5 GHz and 6 GHz bands supporting both WiFi 6 and WiFi 6E. The ANT-W63-MON antennas work with multiple ground plane configurations and the hinged design allows for the antenna to be positioned for optimum performance. The antenna is available with an SMA plug (male pin) or RP-SMA plug (female socket) connector. Features • Performance at 2.4 GHz ― VSWR: ≤ 2.2 ― Peak Gain: 3.2 dBi ― Efficiency: 69% • Performance at 5.150 GHz to 7.125 GHz ― VSWR: ≤ 2.3 ― Peak Gain: 4.2 dBi ― Efficiency: 57% • Hinged design with detents for straight, 45 degree and 90 degree positioning • SMA plug (male pin) or RP-SMA (female socket) Applications • WiFi/WLAN coverage ― WiFi 6E (802.11ax) ― WiFi 6 (802.11ax) ― WiFi 5 (802.11ac) ― WiFi 4 (802.11n) ― 802.11b/g • 2.4 GHz ISM applications ― Bluetooth® ― ZigBee® • U-NII bands 1-4 and 5-8 • Internet of Things (IoT) devices • Smart Home networking • Sensing and remote monitoring |
