CLOCK Output Current ....................................................±50mA

6-Pin μDFN (derate 4.5mW/°C over +70°C) ...............358mW

6-Pin TDFN (derate 18.2mW/°C over +70°C) ..........1455mW

Operating Temperature Range......................... -40°C to +125°C

Junction Temperature......................................................+150°C

Storage Temperature Range............................ -65°C to +150°C

Lead Temperature (soldering, 10s) .................................+300°C

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

DC CHARACTERISTICS

Operating Supply Voltage

2.4

3.6

V

Operating Output Supply Voltage

2.4

3.6

V

Total Operating Supply Current

(Note 2)

922kHz, MAX739_ _ _ _LY

4.4

mA

4MHz, MAX739_ _ _ _RD

5.4

8MHz, MAX739_ _ _ _TP

5.8

16MHz, MAX739_ _ _ _WB

6.5

32MHz, MAX7394_ _ _ YN

9.2

33MHz, MAX7394_ _ _ YQ

9.5

48MHz, MAX7394_ _ _ ZY

12

Total Shutdown Supply Current

Oscillator disabled,

CLKIN = high (MAX7393),

ENABLE = low (MAX7394) (Note 2)

1

2

µA

LOGIC INPUTS (ENABLE, CLKIN)

Logic Input High Voltage

V

Logic Input Low Voltage

V

CLOCK OUTPUT

Output High Voltage

V

Output Low Voltage

0.3

V

Output Rise Time

(Note 3)

5

ns

Output Fall Time

(Note 3)

5

ns

Duty Cycle

(Note 3)

47

%

Startup Time

Time for output to stabilize

2

ms

Output Jitter (Note 3)

Peak-to-peak jitter, 16MHz (MAX7394)

180

ps

Peak-to-peak jitter, 48MHz (MAX7394)

140

MAX7393/MAX7394

Precision Silicon Oscillators with

Enable or Autoenable
